product power:5.4KW（千瓦）
product capacity:6KVA 【View products of the same capacity】
series:Rack RTX series 【View the same series of products】
voltage input and output:Single in single out (220V:220V)
weight:20 kg
size（LWH）:650*482.6*132.5 MM 3U
Shape classification:
Product Features:
●19 "standard rack design, compact structure
● Sine wave output provides the best power supply protection
● Zero conversion time between mains mode and battery mode
● Input zero fire detection function.
● With voltage surge protection function and strong anti-interference function
● Input work factor correction function
● Original supporting battery
● Mobile phone smart monitoring card is supported through mobile phone APP
Monitor UPS data in real time.
| Nominal capacity | 6KVA/5.4KW |
| model | RP 11006GS |
| Rectifier type | IGBT rectifier |
| The rated voltage | 220Vac |
| Input voltage range | 90VAC~300VAC |
| Input frequency range | 40 ~ 70Hz (Adjustable) |
| Input power factor | 0.99 |
| Input protection | Standard surge circuit |
| Rated output | 6KVA/5.4KW |
| Rated output voltage | 220Vac |
| The output voltage | 220VAC（1±1%） |
| The output frequency | Power supply: 46-54Hz Synchronous power supply; 50Hz (mains 40-46Hz or 54-60Hz); Battery: 50 hz |
| Output power factor | 0.9 |
| Way to work | on-line |
| Output waveform | Sine wave |
| Conversion time | Mains ←→ Battery 0ms; Municipal electricity ←→ bypass & LT; 4 ms |
| Overload capacity | 110%-125% of the load can be normal operation for 10 minutes; 125%-150% of the load can run normally for 1 minute, and has output short-circuit protection function. |
| effectiveness | Mains power: ≥93%; battery ≥90% |
| The battery model | Valve-controlled maintenance-free lead-acid battery |
| Mark the machine backup time | 30 minutes to 8 hours are optional |
| Battery pack model | - |
| Typical battery charging time | 10H |
| The battery voltage | 192VDC |
| installation | tower |
| The machine efficiency | Up to 90% |
| Electromagnetic compatibility | ICE/EN/AS 62040-1; CISPR 22 Class A |
| Surge protection | ICE/EN 62040-2, meet ICE/EN 61000-4-5 |
| Protection type | IP20 |
| Interface ports | RS232 with optional Wedpower card and AS400 card |
| The control panel | LED status indicator |
| The alarm | Power outage alarm once 4 seconds: special low battery alarm once per second |
| Communication interface | USB communication interface |
| system | ECO mode; Built-in maintenance bypass switch |
| W | 650.00 mm |
| D | 482.60 mm |
| H | 132.50 mm |
| Machine weight | 20 KG |
| color | black |
| The work environment | -10 °C - 40 °C |
| Working relative humidity | 20%-90% |
| Operating height | 0-1500m |
| Storage temperature | -5 - 45 °C |
| Storage relative humidity | 0 - 95% |
| Store height | 0-1500m |
| The auditory noise is 1 m above the device surface | ≤60.00 dB |
| The standard warranty | 3 years |
6 KVA AC 220V input: AC 220V output
| The input parameters | |
| The input voltage | 220VAC |
| Input wire diameter | 6mm2 |
| Enter zero line diameter | 6mm2 |
| Input ground line diameter | 6mm2 |
| Enter the open | 32A -1P |
| Output parameters | |
| The output voltage | 220VAC |
| Output wire diameter | 6mm2 |
| Output zero line diameter | 6mm2 |
| Output line diameter | 6mm2 |
| Output open | 32A -1P |
| Battery parameters | |
| The external battery is empty | 30A-2P |
| External battery wire diameter | 6mm2 |
